IoT Hub with ADR and Certificate Management – Part 4

February 19, 2026

Understanding X.509 and CSR Workflows

This series uses Microsoft’s new certificate management (preview) that enables devices to receive X.509 certificates automatically during provisioning. This post provides a high-level overview and points you to resources for implementation.

🆕 Preview Feature: Microsoft-backed X.509 certificate management was announced in November 2025 and is currently in public preview.

Not recommended for production workloads. For details, see Certificate Management Overview

Contents:

  1. Introduction
  2. A DPS Primer
  3. Creating DPS, IoT Hub and ADR Instances
  4. Understanding X.509 and CSR Workflows (This Post)
  5. The Device Application

Two Types of Certificates

The new certificate management service makes use of a two-phase approach:

Phase 1: Onboarding Credentials

  • Purpose: Device authenticates to DPS during initial provisioning
  • Options: X.509 certificates (from third-party CA), symmetric keys, or TPM
  • Your responsibility: Pre-install on device before shipment
  • Lifespan: Long-lived or used once for initial authentication

Phase 2: Operational Certificates (Microsoft-Managed)

  • Purpose: Device authenticates to IoT Hub for ongoing operations
  • How it works: Automatically issued by DPS during provisioning via CSR
  • Generated on: Device itself (private key never leaves device)
  • Lifespan: Short-lived (1-90 days), automatically renewed
  • Security: Higher security, no key transport

How It Works

The following diagram shows the complete provisioning flow:

sequenceDiagram
    participant Device as IoT Device
    participant DPS as DPS
    participant ADR as ADR
    participant PKI as PKI-R<br/>(Issuing CA)
    participant Hub as IoT Hub

    Note over Device: Pre-configured with<br/>onboarding credential<br/>and DPS endpoint

    Note over DPS: Configure enrollment:<br/>1) Define onboarding method<br/>2) Link to ADR policy

    Note over ADR: Configure credential<br/>(Root CA) and<br/>policies (ICAs)

    Note over PKI: Manage hierarchy of<br/>Certificate<br/>Authorities (CAs)

    Note over Hub: Store CA and<br/>validate leaf certs

    Device->>DPS: 1. Provisioning Request + CSR
    Note over Device,DPS: Device sends Certificate Signing Request

    DPS->>DPS: 2. Verify onboarding credential

    DPS->>Hub: 3. Provision device to Hub
    DPS->>ADR: 3. Register device in ADR

    Hub-->>DPS: Device created
    ADR-->>DPS: Device registered

    DPS->>PKI: 4. Request operational certificate
    Note over DPS,PKI: Forward CSR to issuing CA

    PKI->>PKI: 5. ICA signs and returns<br/>operational certificate

    PKI-->>DPS: 6. Operational cert + chain

    DPS-->>Device: 6. Return operational cert<br/>+ Hub endpoint

    Device->>Hub: 7. Authenticate with IoT Hub<br/>using operational certificate chain

    Note over Device,Hub: Device uses newly issued<br/>operational certificate for<br/>all future communications

Key Steps:

  1. Device sends provisioning request + CSR – Device authenticates with onboarding credential and submits Certificate Signing Request
  2. DPS verifies onboarding credential – Validates device identity (X.509, symmetric key, or TPM)
  3. Device provisioned to Hub and registered in ADR – Device identity created in both services
  4. Request operational certificate – DPS uses the CSR to request an operational certificate from the PKI. The PKI validates the CSR and forwards it to the policy (issuing CA) linked to the DPS enrollment.
  5. ICA signs and returns operational certificate – Issuing CA issues leaf certificate
  6. Return operational cert + Hub endpoint – DPS sends certificate chain back to device
  7. Device authenticates with IoT Hub – Device uses new operational certificate for all future connections

Microsoft-Managed PKI Architecture

Azure Device Registry (ADR) manages a dedicated PKI for your namespace:

  • Root CA (Credential): One unique root CA per ADR namespace, managed by Microsoft using Azure Managed HSM
  • Issuing CA (Policy): One issuing CA per policy, defines certificate validity (1-90 days)
  • Leaf Certificate (Operational): End-entity certificate issued to device by issuing CA

The issuing CA certificates are automatically synced from ADR to all linked IoT Hubs, enabling Hub to authenticate devices.

Key Features

FeatureDescription
AlgorithmsECC (ECDSA) with NIST P-384 curve, SHA-384 hashing
HSM KeysAzure Managed HSM (no additional subscription required)
Certificate Validity1-90 days (configurable per policy)
ProtocolsHTTP and MQTT during provisioning
RenewalDevice-initiated via DPS registration call
CA SyncAutomatic sync from ADR to linked IoT Hubs

What You’ll Be Doing

For this series, you’ll create onboarding credentials (Phase 1) – we provide automation scripts:

Preview Reminder: Microsoft-backed X.509 certificate management is new and in public preview. Operational certificates (Phase 2) are issued by ADR during provisioning and are not recommended for production workloads during preview.

Quick Setup: Automated X.509 Bootstrap Certificates (if you didn’t already run the full setup script!)

cd scripts

.\setup-x509-attestation.ps1 `
  -RegistrationId "my-device" `
  -DpsName "my-dps-001" `
  -ResourceGroup "my-iot-rg" `
  -enrollmentGroupName "my-device-group"

Manual Setup: Step-by-Step (X.509 Bootstrap Certificates)

If you prefer not to use the script, here are the manual steps to create onboarding credentials (bootstrap certs) and verify your CA with DPS.

We’ll start fresh here so that folks can run through these steps in isolation if needed.

Prerequisites:

# Verify tools are available
az --version                    # Azure CLI
openssl version                 # OpenSSL

If PowerShell shows this error when you run openssl:

openssl : The term 'openssl' is not recognized as the name of a cmdlet, function, script file, or operable program.

Add OpenSSL to your PATH for this session (check if if this is the correct path for your openssl install):

$env:Path = "C:\Program Files\OpenSSL-Win64\bin;$env:Path"

1) Set variables and create folders:

Set variables:

$unique = "dev001"             # make it unique

$resourceGroup = "$unique-skittlesorter-rg"
$dpsName = "$unique-skittlesorter-dps"      # must be globally unique
$registrationId = "$unique-skittlesorter"
$enrollmentGroupName = "$unique-skittlesorter-group"
$certDir = ".\certs"

Create root CA folder:

New-Item -ItemType Directory -Path "$certDir\root" -Force | Out-Null

Create intermediate CA folder:

New-Item -ItemType Directory -Path "$certDir\ca" -Force | Out-Null

Create device folder:

New-Item -ItemType Directory -Path "$certDir\device" -Force | Out-Null

2) Create root and intermediate CA:

Create root CA certificate (self-signed):

openssl req -x509 -new -nodes -newkey rsa:4096 `
  -keyout "$certDir\root\root-ca.key" `
  -out "$certDir\root\root-ca.pem" `
  -days 3650 -sha256 `
  -subj "/CN=$registrationId-root" `
  -addext "basicConstraints=critical,CA:true,pathlen:1" `
  -addext "keyUsage=critical,keyCertSign,cRLSign" `
  -addext "subjectKeyIdentifier=hash" `
  -addext "authorityKeyIdentifier=keyid:always"

Create intermediate CA private key:

openssl genrsa -out "$certDir\ca\intermediate-ca.key" 4096

Create intermediate CA CSR:

openssl req -new `
  -key "$certDir\ca\intermediate-ca.key" `
  -out "$certDir\ca\intermediate-ca.csr" `
  -subj "/CN=$registrationId-intermediate"

Create intermediate CA extensions file:

@"
[ v3_intermediate ]
basicConstraints = critical,CA:true,pathlen:0
keyUsage = critical, keyCertSign, cRLSign
subjectKeyIdentifier = hash
authorityKeyIdentifier = keyid:always,issuer
"@ | Set-Content -Path "$certDir\ca\intermediate-ext.cnf" -Encoding ASCII

Sign intermediate CA with root CA:

openssl x509 -req `
  -in "$certDir\ca\intermediate-ca.csr" `
  -CA "$certDir\root\root-ca.pem" `
  -CAkey "$certDir\root\root-ca.key" `
  -CAcreateserial `
  -out "$certDir\ca\intermediate-ca.pem" `
  -days 1825 -sha256 `
  -extfile "$certDir\ca\intermediate-ext.cnf"
  -extensions v3_intermediate

3) Extract certificate thumbprints:

Extract root CA thumbprint:

$rootX509 = New-Object System.Security.Cryptography.X509Certificates.X509Certificate2("$certDir\root\root-ca.pem")
$rootThumbprint = $rootX509.Thumbprint

Extract intermediate CA thumbprint:

$caX509 = New-Object System.Security.Cryptography.X509Certificates.X509Certificate2("$certDir\ca\intermediate-ca.pem")
$caThumbprint = $caX509.Thumbprint

4) Upload and verify root CA with DPS:

Upload root CA to DPS:

$rootCertName = "$registrationId-root"
az iot dps certificate create --dps-name $dpsName --resource-group $resourceGroup --certificate-name $rootCertName --path "$certDir\root\root-ca.pem"

Get root CA etag and generate verification code:

$rootCert = az iot dps certificate show --dps-name $dpsName --resource-group $resourceGroup --certificate-name $rootCertName -o json | ConvertFrom-Json
$rootEtag = $rootCert.properties.etag

$rootVer = az iot dps certificate generate-verification-code --dps-name $dpsName --resource-group $resourceGroup --certificate-name $rootCertName --etag $rootEtag -o json | ConvertFrom-Json
$rootVerCode = $rootVer.properties.verificationCode
Write-Host "Verification Code: $rootVerCode" -ForegroundColor Cyan

Create root CA verification certificate:

openssl genrsa -out "$certDir\root\verification.key" 2048
openssl req -new -key "$certDir\root\verification.key" -out "$certDir\root\verification.csr" -subj "/CN=$rootVerCode"
openssl x509 -req -in "$certDir\root\verification.csr" -CA "$certDir\root\root-ca.pem" -CAkey "$certDir\root\root-ca.key" -CAcreateserial -out "$certDir\root\verification.pem" -days 1 -sha256

Verify root CA in DPS:

$rootEtag = $rootVer.properties.etag
az iot dps certificate verify --dps-name $dpsName --resource-group $resourceGroup --certificate-name $rootCertName --path "$certDir\root\verification.pem" --etag $rootEtag
Write-Host "✓ Root CA verified in DPS" -ForegroundColor Green

5) Upload and verify intermediate CA with DPS:

Upload intermediate CA to DPS:

$caCertName = "$registrationId-intermediate"
az iot dps certificate create --dps-name $dpsName --resource-group $resourceGroup --certificate-name $caCertName --path "$certDir\ca\intermediate-ca.pem"

Get intermediate CA etag and generate verification code:

$caCert = az iot dps certificate show --dps-name $dpsName --resource-group $resourceGroup --certificate-name $caCertName -o json | ConvertFrom-Json
$caEtag = $caCert.properties.etag

$caVer = az iot dps certificate generate-verification-code --dps-name $dpsName --resource-group $resourceGroup --certificate-name $caCertName --etag $caEtag -o json | ConvertFrom-Json
$caVerCode = $caVer.properties.verificationCode
Write-Host "Verification Code: $caVerCode" -ForegroundColor Cyan

Create intermediate CA verification certificate:

openssl genrsa -out "$certDir\ca\verification.key" 2048
openssl req -new -key "$certDir\ca\verification.key" -out "$certDir\ca\verification.csr" -subj "/CN=$caVerCode"
openssl x509 -req -in "$certDir\ca\verification.csr" -CA "$certDir\ca\intermediate-ca.pem" -CAkey "$certDir\ca\intermediate-ca.key" -CAcreateserial -out "$certDir\ca\verification.pem" -days 1 -sha256

Verify intermediate CA in DPS:

$caEtag = $caVer.properties.etag
az iot dps certificate verify --dps-name $dpsName --resource-group $resourceGroup --certificate-name $caCertName --path "$certDir\ca\verification.pem" --etag $caEtag
Write-Host "✓ Intermediate CA verified in DPS" -ForegroundColor Green

6) Create device bootstrap certificate:

Create device private key and CSR:

openssl genrsa -out "$certDir\device\device.key" 2048
openssl req -new -key "$certDir\device\device.key" -out "$certDir\device\device.csr" -subj "/CN=$registrationId"

Create device extensions file:

@"
[ v3_req ]
basicConstraints = CA:FALSE
keyUsage = critical, digitalSignature, keyEncipherment
extendedKeyUsage = clientAuth
subjectAltName = DNS:$registrationId
authorityKeyIdentifier = keyid:always,issuer
"@ | Set-Content -Path "$certDir\device\device-ext.cnf" -Encoding ASCII

Sign device certificate with intermediate CA:

openssl x509 -req -in "$certDir\device\device.csr" -CA "$certDir\ca\intermediate-ca.pem" -CAkey "$certDir\ca\intermediate-ca.key" -out "$certDir\device\device.pem" -days 365 -sha256 -extfile "$certDir\device\device-ext.cnf" -extensions v3_req

Create certificate chain files:

Get-Content "$certDir\ca\intermediate-ca.pem", "$certDir\root\root-ca.pem" | Set-Content -Path "$certDir\device\chain.pem" -Encoding ASCII
Get-Content "$certDir\device\device.pem", "$certDir\ca\intermediate-ca.pem", "$certDir\root\root-ca.pem" | Set-Content -Path "$certDir\device\device-full-chain.pem" -Encoding ASCII
Write-Host "✓ Device bootstrap certificate created" -ForegroundColor Green

7) Create DPS enrollment group:

az iot dps enrollment-group create --dps-name $dpsName --resource-group $resourceGroup --enrollment-id $enrollmentGroupName --ca-name "$registrationId-intermediate" --credential-policy "default" --provisioning-status enabled

Write-Host "✓ Enrollment group created with CSR-based certificate issuance" -ForegroundColor Green

8) Deploy to device:

Copy to your device:

  • $certDir\device\device.pem – Bootstrap certificate
  • $certDir\device\device.key – Device private key
  • $certDir\device\device-full-chain.pem – Full certificate chain

Store keys securely (TPM/secure element if available).

Setup Complete

You’ve now completed all manual setup steps:

✓ Certificate Authority Chain Created:

  • Root CA (uploaded and verified in DPS)
  • Intermediate CA (uploaded and verified in DPS)
  • Device bootstrap certificate (signed by intermediate CA)

✓ DPS Enrollment Configured:

  • Enrollment group linked to intermediate CA
  • CSR-based certificate issuance enabled
  • Ready for device provisioning

Certificate Files Created:

  • Root: $certDir\root\root-ca.pem
  • Intermediate: $certDir\ca\intermediate-ca.pem
  • Device: $certDir\device\device.pem
  • Device Key: $certDir\device\device.key
  • TLS Chain: $certDir\device\chain.pem (intermediate + root)
  • Full Chain: $certDir\device\device-full-chain.pem (leaf + intermediate + root)

What Happens Next:

  1. Deploy device.pem, device.key, and device-full-chain.pem to your device
  2. Device boots and authenticates to DPS with bootstrap certificate
  3. Device generates new key pair and submits Certificate Signing Request (CSR)
  4. DPS forwards CSR to ADR issuing CA (via credential policy)
  5. ADR issues operational certificate (Phase 2)
  6. Device receives operational certificate from DPS
  7. Device uses operational certificate for all IoT Hub connections

For Detailed Explanations: See Understanding X.509 and CSR Workflows (Deep Dive) for complete technical details, certificate architecture, and advanced scenarios.

Certificate Renewal

Devices are responsible for monitoring operational certificate expiration:

  • Check Valid until date periodically
  • Initiate renewal before expiration (recommended: 7 days before)
  • Generate new CSR and submit to DPS (same as initial provisioning)
  • Receive renewed certificate from ADR

Best Practice: Use Device Twin reported properties to track certificate issuance/expiration dates for monitoring.

Preview Limitations

⚠️ Certificate Revocation: Not supported in preview – disable device in IoT Hub instead
⚠️ Production Use: Not recommended during preview
⚠️ SDK Support: Official Microsoft C# SDKs don’t yet support 2025-07-01-preview API

Learn More

Official Microsoft Documentation:

Deep Dive:

Next Steps

Now that you understand the certificate workflow, you’ll configure enrollment groups to use these certificates:

  • Creating X.509 enrollment groups
  • Linking ADR policies for operational certificate issuance
  • Testing provisioning with certificates

The Device Application →
